Metal Backrest Bench DXF files is a downloadable CNC-ready file package for building a 1400 mm sheet metal bench with backrest for garden, patio, or outdoor seating projects. The finished bench is approximately 33.4 in high, 55.1 in long, and 19.4 in wide.
What You Get
- DXF, SVG, and PDF files for the metal backrest bench design.
- CNC-ready flat pattern files for plasma, laser, or waterjet cutting workflows.
- PDF drawings for sheet metal bending instructions.
- No physical furniture, steel, hardware, fasteners, seat material, or finished item is shipped.
Project Features
- Backrest bench layout for outdoor seating, patio furniture, garden seating, or fabrication projects.
- Designed for CNC cutting and sheet metal bending from 2.0 mm steel.
Finished Size
- Approximate assembled height: 33.4 in / 850 mm.
- Approximate assembled length: 55.1 in / 1400 mm.
- Approximate assembled width: 19.4 in / 492 mm.
Recommended Materials
- 14 gauge / 2.0 mm steel.
Before Cutting
- CADtsy designs are created in millimeters; check file scale and units before sending the DXF files to CAM software.
- Verify kerf, material thickness, bend approach, seating rigidity, and machine settings before fabrication.
- Confirm edge finishing, surface treatment, outdoor exposure, and seating safety before use.
