Digital download. No physical item or shipping required. Check the product description for the exact included files.

Download links are sent by email after checkout. See What You Get below for any additional PDF drawings or instructions.

Purchase grants a limited license; digital files may not be shared, resold, or redistributed. Review the CADtsy license terms.

This downloadable CNC-ready file package is for fabricating a 3.0 mm metal modular tool-storage rack with either a Packout mount-plate top or a flush-worktop layout. No physical rack, toolboxes, material, hardware, or worktop is shipped.

What You Get

  • 3.0 mm DXF, SVG, and PDF cutting files.
  • PDF drawings.
  • Two top-tier layouts: Packout mount plate and flush worktop.

Project Features

  • Modular rack layout for workshop or service-vehicle tool storage.
  • One layout incorporates Packout mounting geometry; the other is prepared for a separately sourced worktop.
  • Requires CNC cutting and sheet-metal bending.

Finished Size

  • Mount-plate version: 853 x 620 x 400 mm.
  • Flush-worktop version: 878 x 620 x 420 mm.

Recommended Materials

  • 3.0 mm / 1/8 in steel or aluminum sheet stock.

Before Cutting

  • CADtsy designs are created in millimeters; check file scale and units before sending files to CAM software.
  • Verify kerf, material thickness, machine settings, and toolpaths for your own CNC setup before fabrication.

Compatibility note: This is an independently designed digital file and is not affiliated with or endorsed by Milwaukee Tool.
